KCS-MD600 FREQUENCY INVERTER
| Input voltage 3 | 80V+/-15% three phase 50/60Hz |
|---|---|
| Output voltage | 380V+/-15% three phase 0~650Hz |
| Max. output frequency | 0~650Hz |
| Carrier wave frequency | y 0.5kHz-16kHz, which will be auto adjusted according to carrier |
| Control Mode | RS485 communication interface is optional, adopt Modbus-RTU communication mode. |
| Starting Torque | 0.5Hz/180%(SVC) |
| Speed adjusting range | 1：200 ( SVC ) 1:1000(FVC) 1:50(V/F) |
| Torque control accuracy | +/-5% |
| Overload Capability | 150% rated current 60s, 180% rated current 3s. |
| Torque boost | Automatic torque boost, manual torque boost 0.1%~30.0%. |
| V/F curve | Three types are available: liner, Multi-point type, N times square (1.2 times square，1.4times square ，1.6 times square ，1.8 times square，2 times square) |
| DC brake | DC brake frequency：0.00Hz~Max. Frequency, Braking time: 0.0s-36.0s; Braking current：0.0%- 100.0%. |
| JOG control | JOG frequency range：0.00Hz-50.00Hz; JOG ACC. /DCC time 0.0s-6500.0s. |
| Multi step speed control | 16 steps speed can be set. |
| In built PID | can realize close loop process control for pressure, temperature, flow etc. |
| Automatic Voltage Regulation | Can Output Constant Voltage Even Grid Voltage Fluctuates. |
| Safety Detection ToPeripherals | Safety Detection To Peripherals When Power On (Such As Grounding, Shortcut Etc.) |
| Textile Swing Control | Triangular Wave Frequency Control Function |
| Timing Control | Setting Range 0H-65535H |
| Run/Stop Command | Keypad Giving Terminals，RS485 Giving. |
| Frequency Source | Digital Giving, Analog Voltage Giving, Analog Current Giving, Impulse Giving，RS485 Giving. |
| Input Terminals | Five Digital Inputs, One Of Which Can Be Used As High Speed Impulse Input, The Max. FrequencyCan Reach 100khz. Source PNP Or NPN Input.Two Analog Inputs. |
| Output Terminals | One High Speed Impulse Output (Which Can Be Set Into Open Circuit Collector), 0khz~100khzSquare Wave Output; One Digital Output; One Relay Output; One Analog Output，0ma-20ma Or 0v-10V Selectable. |
| Protection Function | Motor Shortcut Detection, Input Output Phase Lost Protection, Over Current Protection, OverVoltage Protection, Low Voltage Protection, Over Heat Protection, Over Load Protection. |
| Running Environment | Indoor Avoid Sunlight, Avoid Dust, Erosion Gas, Flammable Gas, Oil Mist, Steam Vapor, WaterDrop, Salt Etc. |
| Altitude | Under 1000m. |
| -10C ~ +40 C. Deration Above 40C | |
| Under 95%RH, No Water Condensation | |
| Vibration | Under 5.9m/S(0.6g) |
| Storage Temperature | -20℃ ~ +60℃ |
