Supplier of Dynamic Breaking Resistor in Rajasthan

Supplier of Dynamic Braking Resistor in Rajasthan

Khushi Control System is a reliable Manufacturer, Exporter, and Supplier of Dynamic Braking Resistor in Rajasthan.

Khushi Control System is a brand partner of Lauritz Knudsen and Inovance, also we sales INVT VFD.

We are based in Ahmedabad and serving Rajasthan, stand out as a leading provider of industrial Automation since 2010.

Specializing in:

AC Drive / VFD panels
Soft Starter
Breaking Resistor
AC Drive Repairing Services
Old VFD

Their Dynamic Braking Resistor (DBR) line is engineered for superior performance—robust, durable, and designed to handle high-energy dissipation in VFD‑based motor systems.

What is a Dynamic Braking Resistor?

A Dynamic Braking Resistor—also called a rheostatic braking resistor—is a high-wattage resistor connected across a motor’s DC bus during braking.

When an electric motor switches to generator mode during deceleration, the resistor absorbs and dissipates the excess energy as heat

This approach ensures:

Quick, controlled stopping
Reduced wear on mechanical braking systems
Prevents overvoltage trips in drives

Technical Specifications:

Operating Temperature: -55°C to +375°C for 1 min
Insulation Resistance: > 100 MΩ at 500V
Dielectric Strength: No breakdown at 2.5 kVAC RMS
Short Time Over Load: 2 x Wattage Rating, 10 sec
Resistance Tolerance: ± 10% (standard) or ± 5% (optional)
Core Material: Ceramic
Coating on Core: Silicon Epoxy Resin
Terminals: Nickel Copper Plated MS Terminals or Temperature Resistant Teflon Cables
Resistor Element: High Grade FeCrAl Alloy
Maximum Temperature: 375°C at full load above an ambient temperature of 40°C
Housing: Anodized Aluminium
Cooling: Air Natural
Standards: IEC 60068-1 & IEC 61180-1 / CE Marked

How It Works (Work of Dynamic Braking Resistor):

Upon braking, the VFD routes generated energy from the motor into the DBR.
Motor’s kinetic energy converts to electrical energy, raising the DC bus voltage.
The DBR safely dissipates this energy as heat, enabling rapid deceleration.
Proper resistor sizing (resistance value + power rating) avoids overheating and ensures efficient thermal performance.

Features of Our Dynamic Braking Resistors:

Wide Power Range: From tens of watts to several kilowatts
Robust Construction: Aluminium, steel, or stainless-steel enclosures—natural or forced air cooling options available
Regulatory Compliance: CE marked, RoHS/REACH compliant
High Reliability: Wire-wound or grid resistor elements in welded housings, designed for industrial use
Thermal Monitoring & Protection: Suitable for high duty cycles; heat sinks and fans ensure safety

Applications:

Industrial Automation Systems
Electric trains
Electric and hybrid automobiles
Elevators and Escalators
Cranes and Hoists

FAQs:

Q1. What power rating is right for my VFD?
Choose based on braking energy and duty cycle. Continuous or peak wattage must match the VFD’s braking profile

Q2. Can it prevent overvoltage trips?
Yes—the resistor absorbs excess DC link voltage during braking, preventing drive faults

Q3. What enclosures are available?
Options include aluminium heat-sink style or galvanized/stainless steel housings, rated IP20 and above, with natural or forced-air cooling

Q4. Do DBRs require maintenance?
No moving parts—they are virtually maintenance-free. Periodic dusting and enclosure checks are recommended.

Q5. Can Khushi integrate DBR into existing panels?
Absolutely—our engineering team handles end-to-end integration, ensuring optimal sizing, wiring, and safety protocols.

Khushi Control System is a Supplier of Dynamic Braking Resistor in Rajasthan including locations in Jaipur, Jodhpur, Pali, Tonk, Udaipur, Alwar, Sikar, Bikaner, Ajmer, Kota, Sri Ganganagar, Bhilwara, Banswara, Bharatpur, Baran, Beawar, Bhiwadi, Hanumangarh, Dholpur, Pratapgarh, Dungarpur, Jaisalmer, Hindaun, Bundi, Chittorgarh, Kishangarh, Sujangarh, Sawai Madhopur, Pushkar, Churu.

For more information about our dynamic breaking resistor, get in touch with Khushi Control System.
